| Display Type | 7 segment LED |
| Display Configuration | 4 digits |
| Electrical Connection | 1Ø-2 wire |
| Accuracy | ± 0.5% of full scale |
| CT Primary | 5 to 4000 A ( Programmable in steps ) |
| CT Secondary | 5A ( fixed )/td> |
| Supply Voltage | 240V AC ±20% (50/60 Hz) , 110V AC ±20% (60Hz) |
| Size | 48 x 96mm |
| Mounting Type | Panel mount |
| Certification | CE, RoHS & UL |
| Display Type | 7 segment LED |
| Display Configuration | 4 digits |
| Electrical Connection | 1Ø-2 wire |
| Accuracy | ± 0.5% of full scale |
| CT Primary | 5 to 4000 A ( Programmable in steps ) |
| CT Secondary | 5A |
| Supply Voltage | 240V AC ±20% (50/60 Hz) , 110V AC ±20% (60Hz) |
| Size | 72 x 72mm |
| Mounting Type | Panel mount |
| Display Type | 7 segment LED |
| Display Configuration | 4 digits |
| Electrical Connection | 1Ø-2 wire |
| Accuracy | ± 0.5% of full scale |
| CT Primary | 5 to 4000 A ( Programmable in steps ) |
| CT Secondary | 5A ( fixed ) |
| Supply Voltage | 240V AC ±20% (50/60 Hz) , 110V AC ±20% (60Hz) |
| Size | 96 x 96mm |
| Mounting Type | Panel mount |
| Display Type | 7 segment LED |
| Display Configuration | 4 digits |
| Electrical Connection | 3Ø-4Wire,3Ø-3Wire,1Ø-2Wire |
| Accuracy | ± 0.5% of Full scale |
| CT Primary | 1 to 999.0kA ( Programmable for any value ) |
| CT Secondary | 1 or 5 A ( Programmable ) |
| Supply Voltage | 230V AC ±20% (50/60 Hz) |
| Size | 96 x 96mm |
| Mounting Type | Panel mount |
| Display Types | LCD with backlight and analog style bargraph Indication |
| Display Configuration | 4 digits |
| Electrical Connection | 3Ø-4 wire |
| Accuracy | ± 0.5% of Full scale |
| CT Primary | 5 to 5000A ( Programmable in steps ) |
| CT Secondary | 5A ( fixed ) |
| Supply Voltage | 240V AC ±20% (50/60 Hz) , 110V AC ±20% (60Hz) |
| Size | 72 x 72mm |
| Mounting Type | Panel mount |
| Certification | CE, RoHS & UL |
