Part Number | Nominal Cross Sectional Area (Sq. mm) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Approx Overall Diameter (mm) | Approx. Net Weight (kg/km) |
---|---|---|---|---|---|
011600100004 | 4 | 0.70 | 1.40 | 8.0 | 107 |
011600100006 | 6 | 0.70 | 1.40 | 8.5 | 132 |
011600100010 | 10 | 0.70 | 1.40 | 9.5 | 181 |
0116001000160 | 16 | 0.70 | 1.40 | 10.5 | 247 |
011600100025 | 25 | 0.90 | 1.40 | 12.0 | 358 |
011600100035 | 35 | 0.90 | 1.40 | 13.0 | 466 |
011600100050 | 50 | 1.00 | 1.40 | 14.0 | 545 |
011600100070 | 70 | 1.10 | 1.40 | 16.0 | 765 |
011600100095 | 95 | 1.10 | 1.50 | 18.0 | 1022 |
011600100120 | 120 | 1.20 | 1.50 | 20.0 | 1267 |
011600100150 | 150 | 1.40 | 1.60 | 22.0 | 1556 |
011600100185 | 185 | 1.60 | 1.60 | 24.0 | 1928 |
011600100240 | 240 | 1.70 | 1.70 | 27.0 | 2501 |
011600100300 | 300 | 1.80 | 1.80 | 29.0 | 3108 |
011600100400 | 400 | 2.00 | 1.90 | 32.0 | 3923 |
011600100500 | 500 | 2.20 | 2.00 | 36.0 | 4999 |
011600100630 | 630 | 2.40 | 2.20 | 40.0 | 6414 |
