Part Number | Nominal Cross Sectional Area (Sq. mm) | Nominal Insulation Thickness (mm) | Number *Nominal Dia. of Strands | Approx. Overall Diameter (mm) | Max. DC Conductor Resistance at 20OC (Ω/km) | Current Rating (Amps) | |
---|---|---|---|---|---|---|---|
Casing | Concealed | ||||||
01030101xx40 | 1 | 0.7 | 37/0.20 | 2.6 | 19.5 | 12 | 11 |
01030102xx40 | 1.5 | 0.7 | 37/0.22 | 3.0 | 13.3 | 16 | 15 |
01030103xx40 | 2.5 | 0.8 | 61/0.22 | 3.6 | 7.98 | 23 | 19 |
01030104xx40 | 4 | 0.8 | 61/0.30 | 4.1 | 4.95 | 30 | 26 |
Test | Test Method | Values |
---|---|---|
Limited Oxygen Index | IS 10810 P-58 | > 29% |
Limited Temp. Index | IS 10810 P-64 | >250 °C |
