Part Number | Nominal Cross Sectional Area (Sq. mm) | Nominal Insulation Thickness (mm) | Overall Diameter Lower Limit (mm) | Overall Diameter Upper Limit (mm) | Approx. Net Weight (kg/km) |
---|---|---|---|---|---|
01130101xx60 | 1.5 | 0.70 | 2.70 | 3.40 | 19 |
01130102xx60 | 2.5 | 0.80 | 3.30 | 4.10 | 33 |
01130103xx60 | 4 | 0.80 | 3.80 | 4.70 | 50 |
01130104xx60 | 6 | 0.80 | 4.30 | 5.40 | 74 |
01130105xx60 | 10 | 1.00 | 5.60 | 7.00 | 126 |
01130106xx60 | 16 | 1.00 | 6.40 | 8.00 | 184 |
01130107xx60 | 25 | 1.20 | 8.10 | 10.10 | 295 |
01130108xx60 | 35 | 1.20 | 9.00 | 11.30 | 375 |
01130109xx60 | 50 | 1.40 | 10.60 | 13.20 | 510 |
01130110xx60 | 70 | 1.40 | 12.10 | 15.10 | 710 |
01130111xx60 | 95 | 1.60 | 14.10 | 17.60 | 950 |
01130112xx60 | 120 | 1.60 | 15.60 | 19.40 | 1240 |
01130113xx60 | 150 | 1.80 | 17.30 | 21.60 | 1530 |
01130114xx60 | 185 | 2.00 | 19.30 | 24.10 | 1800 |
01130115xx60 | 240 | 2.20 | 22.00 | 27.50 | 2500 |
01130116xx60 | 300 | 2.40 | 24.50 | 30.60 | 2990 |
01130117xx60 | 400 | 2.60 | 27.50 | 34.30 | 3860 |
01130118xx60 | 500 | 2.80 | 30.50 | 38.20 | 4900 |
01130119xx60 | 630 | 2.80 | 34.00 | 42.50 | 6370 |
