| PartNumber | Nominal Cross Sectional Area(Sq. mm) | Minimum No. of Strands in Conductor | Nominal Thickness of Insulation (mm) | Nominal Thickness of Outer Sheath (mm) | Approx.Overall Diameter(mm) | Approx. Net Wt.of Cable (Kg/Km) | ||
|---|---|---|---|---|---|---|---|---|
| AL | CU | AL CableAYY | CU CableYY | |||||
| 110100100016 | 16 | 6 | 6 | 1.0 | 1.8 | 11 | 160 | 260 |
| 110100100025 | 25 | 6 | 6 | 1.2 | 1.8 | 13 | 210 | 365 |
| 110100100035 | 35 | 6 | 6 | 1.2 | 1.8 | 14 | 250 | 460 |
| 110100100050 | 50 | 6 | 6 | 1.4 | 1.8 | 16 | 300 | 610 |
| 110100100070 | 70 | 12 | 12 | 1.4 | 1.8 | 17 | 400 | 830 |
| 110100100095 | 95 | 15 | 15 | 1.6 | 1.8 | 19 | 500 | 1100 |
| 110100100120 | 120 | 15 | 18 | 1.6 | 2.0 | 21 | 600 | 1350 |
| 110100100150 | 150 | 15 | 18 | 1.8 | 2.0 | 23 | 750 | 1680 |
| 110100100185 | 185 | 30 | 30 | 2.0 | 2.0 | 25 | 900 | 2050 |
| 110100100240 | 240 | 30 | 34 | 2.2 | 2.0 | 28 | 1100 | 2600 |
| 110100100300 | 300 | 30 | 34 | 2.4 | 2.0 | 30 | 1350 | 3200 |
| 110100100400 | 400 | 53 | 53 | 2.6 | 2.2 | 35 | 1700 | 4200 |
| 110100100500 | 500 | 53 | 53 | 3.0 | 2.2 | 38 | 2150 | 5250 |
| 110100100630 | 630 | 53 | 53 | 3.4 | 2.4 | 43 | 2750 | 6650 |
| 110100100800 | 800 | 53 | 53 | 3.4 | 2.4 | 48 | 3300 | 8250 |
| 110100101000 | 1000 | 53 | 53 | 3.4 | 2.6 | 52 | 4100 | 10300 |
