Part Number | Nominal Cross-Sectional Area (Sq. mm) | Max. Strand Diameter (mm) | Max. DC Conductor Resistance (Ω/km) | Total Radial Thickness of Covering (mm) | Maximum Cable Diameter (mm) | Approx. Weight (kg/km) |
---|---|---|---|---|---|---|
1207y0100010 | 10 | 0.30 | 1.91 | 3.2 | 10.0 | 180 |
1207y0100016 | 16 | 0.30 | 1.21 | 3.2 | 11.5 | 250 |
1207y0100025 | 25 | 0.30 | 0.78 | 3.2 | 13.0 | 350 |
1207y0100035 | 35 | 0.30 | 0.554 | 3.2 | 14.5 | 460 |
1207y0100050 | 50 | 0.30 | 0.386 | 3.5 | 17.0 | 650 |
1207y0100070 | 70 | 0.30 | 0.272 | 3.8 | 19.0 | 880 |
1207y0100095 | 95 | 0.30 | 0.206 | 4.2 | 21.5 | 1170 |
1207y0100120 | 120 | 0.30 | 0.161 | 4.5 | 24.0 | 1430 |
1207y0100150 | 150 | 0.30 | 0.129 | 4.8 | 26.0 | 1720 |
