Part Number | No. of Cores & Nominal Cross Sectional Area(Sq. mm) | Approx. Cable Diameter (mm) | Approx. Copper Weight (kg/km) | Approx. Cable Weight (kg/km) |
---|---|---|---|---|
040100201050 | 2 x 0.5 | 4.8 | .7 | 30 |
040100311050 | 3G 0.5 | 5.1 | 3.0 | 37 |
040100301050 | 3 x 0.5 | 5.1 | 3.0 | 37 |
040100411050 | 4G 0.5 | 5.6 | 7.4 | 46 |
040100401050 | 4 x 0.5 | 5.6 | 7.4 | 46 |
040100511050 | 5G 0.5 | 6.0 | 1.7 | 55 |
040100501050 | 5 x 0.5 | 6.0 | 1.7 | 55 |
040100711050 | 7G 0.5 | 6.7 | 0.4 | 72 |
040100701050 | 7 x 0.5 | 6.7 | 0.4 | 72 |
040101011050 | 10G 0.5 | 8.8 | 3.5 | 115 |
040101211050 | 12G 0.5 | 8.9 | 2.2 | 126 |
040101811050 | 18G 0.5 | 10.5 | 78.2 | 180 |
040102511050 | 25G 0.5 | 12.9 | 108.6 | 263 |
040103411050 | 34G 0.5 | 14.3 | 147.8 | 337 |
040104211050 | 42G 0.5 | 16.6 | 182.5 | 437 |
040100201075 | 2 x 0.75 | 5.3 | 13.0 | 39 |
040100311075 | 3G 0.75 | 5.6 | 19.6 | 48 |
040100301075 | 3 x 0.75 | 5.6 | 19.6 | 48 |
040100411075 | 4G 0.75 | 6.1 | 26.1 | 59 |
040100401075 | 4 x 0.75 | 6.1 | 26.1 | 59 |
040100511075 | 5G 0.75 | 6.9 | 32.6 | 76 |
040100501075 | 5 x 0.75 | 6.9 | 32.6 | 76 |
040100711075 | 7G 0.75 | 7.6 | 45.6 | 97 |
040100701075 | 7 x 0.75 | 7.6 | 45.6 | 97 |
040101011075 | 10G 0.75 | 10.0 | 5.2 | 156 |
040101211075 | 12G 0.75 | 10.1 | 8.2 | 171 |
040101811075 | 18G 0.75 | 11.9 | 17.3 | 247 |
040102511075 | 25G 0.75 | 14.6 | 63.0 | 357 |
040103411075 | 34G 0.75 | 15.7 | 21.6 | 446 |
040104111075 | 41G 0.75 | 17.4 | 67.3 | 543 |
040100200001 | 2 x 1 | 5.6 | 17.4 | 46 |
040100310001 | 3G 1 | 6.0 | 26.1 | 59 |
040100300001 | 3 x 1 | 6.0 | 26.1 | 59 |
040100410001 | 4G 1 | 6.8 | 34.8 | 77 |
040100400001 | 4 x 1 | 6.8 | 34.8 | 77 |
040100510001 | 5G 1 | 7.5 | 43.5 | 93 |
040100500001 | 5 x 1 | 7.5 | 43.5 | 93 |
040100710001 | 7G 1 | 8.9 | 60.8 | 132 |
040101010001 | 10G 1 | 10.8 | 86.9 | 191 |
040101210001 | 12G 1 | 11.1 | 104.3 | 215 |
040101810001 | 18G 1 | 13.2 | 156.5 | 311 |
040102510001 | 25G 1 | 16.2 | 217.3 | 452 |
040103410001 | 34G 1 | 18.1 | 295.5 | 587 |
040104110001 | 41G 1 | 19.7 | 356.4 | 700 |
040100201105 | 2 x 1.5 | 6.3 | 25.5 | 61 |
040100311105 | 3G 1.5 | 6.7 | 38.2 | 78 |
040100301105 | 3 x 1.5 | 6.7 | 38.2 | 78 |
040100411105 | 4G 1.5 | 7.3 | 50.9 | 98 |
040100401105 | 4 x 1.5 | 7.3 | 50.9 | 98 |
040100511105 | 5G 1.5 | 8.2 | 63.7 | 123 |
040100501105 | 5 x 1.5 | 8.2 | 63.7 | 123 |
040100711105 | 7G 1.5 | 9.0 | 89.1 | 160 |
040100701105 | 7 x 1.5 | 9.0 | 89.1 | 160 |
040101211105 | 12G 1.5 | 12.1 | 152.8 | 280 |
040101811105 | 18G 1.5 | 14.5 | 229.2 | 412 |
040102511105 | 25G 1.5 | 17.2 | 318.3 | 576 |
040103411105 | 34G 1.5 | 19.6 | 432.9 | 766 |
040104111105 | 41G 1.5 | 21.3 | 522.0 | 915 |
040100201205 | 2 x 2.5 | 7.6 | 42.4 | 93 |
040100311205 | 3G 2.5 | 8.3 | 63.7 | 124 |
040100411205 | 4G 2.5 | 9.1 | 84.9 | 157 |
040100511205 | 5G 2.5 | 10.2 | 106.1 | 196 |
040100711205 | 7G 2.5 | 11.2 | 148.5 | 256 |
040101211205 | 12G2.5 | 14.8 | 254.6 | 443 |
040100410004 | 4G 4 | 10.8 | 135.0 | 234 |
040100510004 | 5G 4 | 12.1 | 168.7 | 292 |
040100710004 | 7G 4 | 13.3 | 236.2 | 383 |
040100410006 | 4G 6 | 13.0 | 202.4 | 345 |
040100510006 | 5G 6 | 14.5 | 253.1 | 430 |
040100710006 | 7G 6 | 16.0 | 354.3 | 566 |
040100410010 | 4G 10 | 15.5 | 344.7 | 539 |
040100510010 | 5G 10 | 17.1 | 430.8 | 666 |
040100710010 | 7G 10 | 19.0 | 603.2 | 888 |
040100410016 | 4G 16 | 18.8 | 574.1 | 852 |
