Part Number | No. of Cores & Nominal Cross Sectional Area(Sq. mm) | Approx. CableDiameter (mm) | Approx. CopperWeight (kg/km) | Approx. CableWeight (kg/km) |
---|---|---|---|---|
040400201050 | 2 x 0.5 | 5.9 | 8.7 | 39 |
040400311050 | 3G 0.5 | 6.2 | 13.0 | 45 |
040400411050 | 4G 0.5 | 6.9 | 17.4 | 57 |
040400511050 | 5G 0.5 | 7.4 | 21.7 | 67 |
040400711050 | 7G 0.5 | 9.1 | 30.4 | 100 |
040401211050 | 12G 0.5 | 11.3 | 52.2 | 158 |
040401811050 | 18G 0.5 | 13.2 | 78.2 | 220 |
040402511050 | 25G 0.5 | 15.0 | 108.6 | 290 |
040400201075 | 2 x 0.75 | 6.4 | 13.0 | 48 |
040400311075 | 3G 0.75 | 6.8 | 19.6 | 58 |
040400411075 | 4G 0.75 | 7.4 | 26.1 | 71 |
040400511075 | 5G 0.75 | 8.6 | 32.6 | 94 |
040400711075 | 7G 0.75 | 10.0 | 45.6 | 128 |
040401211075 | 12G 0.75 | 12.4 | 78.2 | 203 |
040401811075 | 18G 0.75 | 14.4 | 117.3 | 283 |
040402511075 | 25G 0.75 | 17.2 | 163.0 | 401 |
040400200001 | 2 x 1 | 6.8 | 17.4 | 57 |
040400310001 | 3G 1 | 7.2 | 26.1 | 69 |
040400410001 | 4G 1 | 8.2 | 34.8 | 90 |
040400510001 | 5G 1 | 9.0 | 43.5 | 110 |
040400710001 | 7G 1 | 11.1 | 60.8 | 163 |
040401210001 | 12G 1 | 13.2 | 104.3 | 244 |
040401810001 | 18G 1 | 15.4 | 156.5 | 344 |
040402510001 | 25G 1 | 19.0 | 217.3 | 507 |
040403410001 | 34G 1 | 21.8 | 295.5 | 675 |
040404110001 | 41G 1 | 23.4 | 356.4 | 791 |
040400201105 | 2 x 1.5 | 7.4 | 25.5 | 71 |
040400311105 | 3G 1.5 | 8.3 | 38.2 | 94 |
040400411105 | 4G 1.5 | 9.0 | 50.9 | 116 |
040400511105 | 5G 1.5 | 9.8 | 63.7 | 140 |
040400711105 | 7G 1.5 | 12.2 | 89.1 | 209 |
040401211105 | 12G 1.5 | 14.5 | 152.8 | 317 |
040401811105 | 18G 1.5 | 17.6 | 229.2 | 471 |
040402511105 | 25G 1.5 | 20.7 | 318.3 | 653 |
040404111105 | 41G 1.5 | 26.3 | 522.0 | 1060 |
040400311205 | 3G 2.5 | 9.7 | 63.7 | 139 |
040400411205 | 4G 2.5 | 11.0 | 84.9 | 181 |
040400511205 | 5G 2.5 | 12.1 | 106.1 | 221 |
040400711205 | 7G 2.5 | 14.2 | 148.5 | 307 |
040401211205 | 12G 2.5 | 17.8 | 254.6 | 500 |
