Part Number | No. of Cores and Nominal Cross Sectional Area (Sq. mm) | Approx. CableDiameter (mm) | Approx. Copper Weight (kg/km) | Approx. Cable Weight (kg/km) |
---|---|---|---|---|
030900211050 | 2 x 0.5 | 4.8 | 9.5 | 35 |
030900311050 | 3G 0.5 | 5.1 | 14.0 | 42 |
030900301050 | 3 x 0.5 | 5.1 | 14.2 | 42 |
030900411050 | 4G 0.5 | 5.6 | 19.0 | 51 |
030900401050 | 4 x 0.5 | 5.6 | 19.0 | 51 |
030900511050 | 5G 0.5 | 6.0 | 24.0 | 61 |
030900501050 | 5 x 0.5 | 6.0 | 24.0 | 61 |
030900611050 | 6G 0.5 | 6.6 | 28.5 | 74 |
030900711050 | 7G 0.5 | 6.7 | 33.5 | 80 |
030900701050 | 7 x 0.5 | 6.7 | 33.5 | 80 |
030900811050 | 8G 0.5 | 7.9 | 38.0 | 103 |
030900801050 | 8 x 0.5 | 7.9 | 38.0 | 103 |
030901011050 | 10G 0.5 | 8.8 | 47.5 | 130 |
030901211050 | 12G 0.5 | 8.9 | 57.0 | 140 |
030901201050 | 12 x 0.5 | 8.9 | 57.0 | 140 |
030901411050 | 14G 0.5 | 10.0 | 66.5 | 170 |
030901611050 | 16G 0.5 | 10.2 | 76.0 | 184 |
030901811050 | 18G 0.5 | 10.5 | 85.5 | 200 |
030902011050 | 20G 0.5 | 11.8 | 95.0 | 239 |
030902111050 | 21G 0.5 | 11.9 | 100.0 | 246 |
030902511050 | 25G 0.5 | 12.9 | 118.5 | 293 |
030903011050 | 30G 0.5 | 13.5 | 142.5 | 329 |
030903211050 | 32G 0.5 | 14.0 | 152.0 | 354 |
030903411050 | 34G 0.5 | 14.3 | 161.5 | 373 |
030904011050 | 40G 0.5 | 15.3 | 190.0 | 429 |
030904211050 | 42G 0.5 | 16.6 | 199.0 | 486 |
030905011050 | 50G 0.5 | 18.2 | 237.0 | 581 |
030905211050 | 52G 0.5 | 18.2 | 246.5 | 589 |
030906111050 | 61G 0.5 | 19.4 | 289.5 | 680 |
030906511050 | 65G 0.5 | 20.4 | 308.5 | 740 |
030908011050 | 80G 0.5 | 22.4 | 379.5 | 898 |
030910011050 | 100G 0.5 | 25.0 | 474.0 | 1119 |
030900201075 | 2 x 0.75 | 5.3 | 14.5 | 44 |
030900311075 | 3G 0.75 | 5.6 | 21.5 | 54 |
030900301075 | 3 x 0.75 | 5.6 | 21.5 | 54 |
030900411075 | 4G 0.75 | 6.1 | 28.5 | 66 |
030900401075 | 4 x 0.75 | 6.1 | 28.5 | 66 |
030900511075 | 5G 0.75 | 6.9 | 36.0 | 85 |
030900501075 | 5 x 0.75 | 6.9 | 36.0 | 85 |
030900611075 | 6G 0.75 | 7.4 | 43.0 | 100 |
030900601075 | 6 x 0.75 | 7.4 | 43.0 | 100 |
030900711075 | 7G 0.75 | 7.6 | 50.0 | 108 |
030900701075 | 7 x 0.75 | 7.6 | 50.0 | 108 |
030900811075 | 8G 0.75 | 9.4 | 57.0 | 150 |
030900801075 | 8 x 0.75 | 9.4 | 57.0 | 150 |
030900911075 | 9G 0.75 | 9.8 | 64.0 | 164 |
030901011075 | 10G 0.75 | 10.0 | 71.0 | 175 |
030901211075 | 12G 0.75 | 10.1 | 85.5 | 190 |
030901201075 | 12 x 0.75 | 10.1 | 85.5 | 190 |
030901411075 | 14G 0.75 | 10.7 | 100.0 | 215 |
030901511075 | 15G 0.75 | 11.3 | 107.0 | 238 |
030901811075 | 18G 0.75 | 11.9 | 128.0 | 273 |
030901911075 | 19G 0.75 | 12.3 | 135.0 | 288 |
030902011075 | 20G 0.75 | 13.0 | 142.5 | 315 |
030902111075 | 21G 0.75 | 13.2 | 149.5 | 327 |
030902511075 | 25G 0.75 | 14.6 | 178.0 | 396 |
030902711075 | 27G 0.75 | 14.8 | 192.0 | 416 |
030903211075 | 32G 0.75 | 15.7 | 228.0 | 477 |
030903411075 | 34G 0.75 | 15.7 | 242.0 | 491 |
030903711075 | 37G 0.75 | 16.1 | 263.0 | 521 |
030904011075 | 40G 0.75 | 16.6 | 284.5 | 559 |
030904111075 | 41G 0.75 | 17.4 | 292.0 | 599 |
030904211075 | 42G 0.75 | 17.7 | 299.0 | 613 |
030905011075 | 50G 0.75 | 19.2 | 356.0 | 725 |
030906111075 | 61G 0.75 | 20.3 | 434.0 | 846 |
030906511075 | 65G 0.75 | 21.4 | 462.5 | 922 |
030908011075 | 80G 0.75 | 22.9 | 569.0 | 1087 |
030910011075 | 100G 0.75 | 27.8 | 711.5 | 1494 |
030900200001 | 2 x 1 | 5.6 | 19.0 | 52 |
030900310001 | 3G 1 | 6.0 | 28.5 | 66 |
030900300001 | 3 x 1 | 6.0 | 28.5 | 66 |
030900410001 | 4G 1 | 6.8 | 38.0 | 86 |
030900400001 | 4 x 1 | 6.8 | 38.0 | 86 |
030900510001 | 5G 1 | 7.5 | 47.5 | 104 |
030900500001 | 5 x 1 | 7.5 | 47.5 | 104 |
030900610001 | 6G 1 | 8.3 | 57.0 | 128 |
030900710001 | 7G 1 | 8.9 | 66.5 | 148 |
030900700001 | 7 x 1 | 8.9 | 66.5 | 148 |
030900810001 | 8G 1 | 9.7 | 76.0 | 174 |
030900910001 | 9G 1 | 10.5 | 85.5 | 199 |
030901010001 | 10G 1 | 10.8 | 95.0 | 215 |
030901000001 | 10 x 1 | 10.8 | 95.0 | 215 |
030901210001 | 12G 1 | 11.1 | 114.0 | 239 |
030901200001 | 12 x 1 | 11.1 | 114.0 | 239 |
030901410001 | 14G 1 | 11.7 | 133.0 | 272 |
030901610001 | 16G 1 | 12.5 | 152.0 | 308 |
030901810001 | 18G 1 | 13.2 | 171.0 | 346 |
030901800001 | 18 x 1 | 13.2 | 171.0 | 346 |
030901910001 | 19G 1 | 13.5 | 180.5 | 363 |
030902010001 | 20G 1 | 14.0 | 190.0 | 388 |
030902000001 | 20 x 1 | 14.0 | 190.0 | 388 |
030902110001 | 21G 1 | 14.2 | 199.5 | 403 |
030902410001 | 24G 1 | 15.7 | 228.0 | 477 |
030902510001 | 25G 1 | 16.2 | 237.5 | 504 |
030902500001 | 25 x 1 | 16.2 | 237.5 | 504 |
030902610001 | 26G 1 | 16.2 | 246.5 | 512 |
030902710001 | 27G 1 | 16.4 | 256.0 | 528 |
030903010001 | 30G 1 | 16.6 | 284.5 | 561 |
030903410001 | 34G 1 | 18.1 | 322.5 | 652 |
030903610001 | 36G 1 | 18.1 | 341.5 | 668 |
030903710001 | 37G 1 | 19.1 | 351.0 | 719 |
030904010001 | 40G 1 | 19.6 | 379.5 | 767 |
030904000001 | 40 x 1 | 19.6 | 379.5 | 767 |
030904110001 | 41G 1 | 19.7 | 389.0 | 776 |
030904210001 | 42G 1 | 19.7 | 398.5 | 785 |
030905010001 | 50G 1 | 21.8 | 474.5 | 952 |
030905610001 | 56G 1 | 22.3 | 531.0 | 1027 |
030906110001 | 61G 1 | 23.1 | 578.5 | 1107 |
030906510001 | 65G 1 | 23.7 | 616.5 | 1175 |
030908010001 | 80G 1 | 26.4 | 759.0 | 1451 |
030910010001 | 100G 1 | 29.4 | 948.5 | 1803 |
030900201105 | 2 x 1.5 | 6.3 | 29.0 | 69 |
030900311105 | 3G 1.5 | 6.7 | 43.5 | 87 |
030900301105 | 3 x 1.5 | 6.7 | 43.5 | 87 |
030900411105 | 4G 1.5 | 7.3 | 58.0 | 109 |
030900401105 | 4 x 1.5 | 7.3 | 58.0 | 109 |
030900511105 | 5G 1.5 | 8.2 | 72.5 | 137 |
030900501105 | 5 x 1.5 | 8.2 | 72.5 | 137 |
030900611105 | 6G 1.5 | 8.9 | 86.7 | 162 |
030900711105 | 7G 1.5 | 9 | 101.0 | 176 |
030900701105 | 7 x 1.5 | 9 | 101.0 | 176 |
030900811105 | 8G 1.5 | 10.6 | 116.0 | 224 |
030900801105 | 8 x 1.5 | 10.6 | 116.0 | 224 |
030900911105 | 9G 1.5 | 11.5 | 130.0 | 259 |
030901011105 | 10G 1.5 | 11.7 | 145.0 | 276 |
030901111105 | 11G 1.5 | 12.0 | 159.0 | 299 |
030901211105 | 12G 1.5 | 12.1 | 173.5 | 311 |
030901201105 | 12 x 1.5 | 12.1 | 173.5 | 311 |
030901411105 | 14G 1.5 | 12.9 | 202.5 | 357 |
030901611105 | 16G 1.5 | 13.6 | 202.5 | 403 |
030901811105 | 18G 1.5 | 14.5 | 260.0 | 455 |
030902111105 | 21G 1.5 | 15.7 | 303.5 | 533 |
030902511105 | 25G 1.5 | 17.2 | 361.0 | 637 |
030902611105 | 26G 1.5 | 17.3 | 361.0 | 654 |
030903211105 | 32G 1.5 | 19.1 | 462.5 | 799 |
030903411105 | 34G 1.5 | 19.8 | 491.0 | 854 |
030904111105 | 41G 1.5 | 21.0 | 592.5 | 994 |
030905011105 | 50G 1.5 | 23.7 | 722.5 | 1240 |
030906111105 | 61G 1.5 | 25.2 | 881.5 | 1461 |
030906511105 | 65G 1.5 | 26.0 | 939.0 | 1550 |
030900201205 | 2 x 2.5 | 7.6 | 40.1 | 100 |
030900311205 | 3G 2.5 | 8.3 | 60.2 | 129 |
030900411205 | 4G 2.5 | 9.1 | 80.3 | 162 |
030900511205 | 5G 2.5 | 10.2 | 100.3 | 203 |
030900711205 | 7G 2.5 | 11.2 | 140.4 | 261 |
030901211205 | 12G 2.5 | 14.8 | 240.8 | 452 |
030901411205 | 14G 2.5 | 15.7 | 280.9 | 517 |
030901811205 | 18G 2.5 | 17.5 | 361.1 | 653 |
030902511205 | 25G 2.5 | 20.8 | 501.6 | 915 |
030903411205 | 34G 2.5 | 24.4 | 682.1 | 1253 |
030905011205 | 50G 2.5 | 29.4 | 1003.2 | 1831 |
030900310004 | 3G 4 | 9.9 | 96.0 | 192 |
030900410004 | 4G 4 | 10.8 | 128.0 | 241 |
030900510004 | 5G 4 | 12.1 | 159.5 | 301 |
030900710004 | 7G 4 | 13.3 | 223.5 | 390 |
030901110004 | 11G 4 | 17.6 | 351.0 | 649 |
030901210004 | 12G 4 | 18.1 | 383.0 | 696 |
030900310006 | 3G 6 | 1.7 | 144.0 | 277 |
030900410006 | 4G 6 | 13.0 | 191.5 | 354 |
030900510006 | 5G 6 | 14.5 | 239.5 | 441 |
030900710006 | 7G 6 | 16.0 | 335.0 | 574 |
030900310010 | 3G 10 | 14.2 | 244.5 | 436 |
030900410010 | 4G 10 | 15.5 | 326.0 | 548 |
030900510010 | 5G 10 | 17.1 | 407.5 | 676 |
030900710010 | 7G 10 | 19.0 | 570.5 | 892 |
030900410016 | 4G 16 | 18.8 | 543.0 | 860 |
030900510016 | 5G 16 | 21.0 | 678.5 | 1074 |
030900710016 | 7G 16 | 23.4 | 950.0 | 1424 |
030900410025 | 4G 25 | 23.4 | 844.5 | 1335 |
030900510025 | 5G 25 | 25.8 | 1055.5 | 1648 |
030900710025 | 7G 25 | 28.7 | 1478.0 | 2184 |
030900410035 | 4G 35 | 26.4 | 1189.0 | 1795 |
030900510035 | 5G 35 | 29.6 | 1486.5 | 2251 |
