UL 2587

Applications :-
  • Used in machine tools, control systems, connection between control panels and machines, assembly lines and other industrial equipment and moderate flexing applications.
Technical Data :-
  • Standard : UL – Std. 758; Control cable of special – PVC to UL AWM; Style 2587 cores according to UL 1015
  • NominalVoltage : 600V
  • TestVoltage : 3000V
  • Temperature Range : Flexing -5°C to +90°C.
  • Fixed installation -20°C to + 90°C
  • Insulation Resistance : Min 20 MΩ x km
  • Bending Radius : For permanent approx, 7.5 x cable ø
Cable Design Parameters :-
  • Kindly complete the part numbers for these cables by adding the suffix (in place of ‘z’) for the sheath colour required: 1 – black (RAL 9005), 3 – grey (RAL 7001).
Part NumberAWG No.No. of Cores & Nominal Cross Sectional Area (Sq. mm)Approx. Cable Diameter (mm)Approx. Copper Weight (kg/km)Approx Cable Weight (kg/km)
06060101000z2216.47.953
06060102000z3217.111.968.5
06060103000z4218.515.896.9
06060104000z6211123.7157.9
06060105000z102111.739.5190.7
06060106000z122112.147.4208.4
06060107000z162113.563.2262.2
06060108000z182115.371.1327.8
06060109000z242117.894.8444.5
06060110000z2196.811.962.4
06060111000z3197.117.873.5
06060112000z4198.223.796.5
06060113000z6199.835.6139.3
06060114000z101912.559.3229.5
06060115000z12191371.1252.2
06060116000z161915.594.8353.8
06060117000z181916.3106.7393.8
06060118000z241919142.3535
06060119000z2187.115.870.4
06060120000z3187.523.783.8
06060121000z4188.531.6110.1
06060122000z61810.247.4159.5
06060123000z101813.179263.7
06060124000z121813.694.8291.1
06060125000z161816.2126.5405.8
06060126000z181817142.3452.2
06060127000z241819.9189.7615
06060128000z2167.623.485.2
06060129000z3168.335.1107.7
06060130000z4169.146.8135.1
06060131000z6161170.2196.8
06060132000z101614.1117326.7
06060133000z121615.6140.4398.3
06060134000z161617.3187.2501.9
06060135000z181618.3210.6560.2
06060136000z241621.4280.8762.5
06060137000z2148.739119.9
06060138000z3149.258.5146.6
06060139000z41410.278185.4
06060140000z51412.397.5255.8
06060141000z2129.862162.6
06060142000z31210.493202
06060143000z41211.6124257.3
06060144000z51214155353.7
06060145000z21010.993214.7
06060146000z31011.6139.5270.6
06060147000z41012.9186346.5
06060148000z285.3158.4402.6
06060149000z386.2237.6501.4
06060150000z488316.8638.1
06060151000z269.4263.8654.5
06060152000z361.1395.7843.3
06060153000z463.5527.61074.8
06060154000z242.2410.4911.1
06060155000z343.6615.61153.6
06060156000z446.3820.71479.2
06060157000z224.7596.71201.9
06060158000z326.3895.11540.7
06060159000z420.31193.42053.9
