Part Number | No. of Pairs & Nominal Cross Sectional Area (Sq. mm) | Approx. Cable Diameter (mm) | Approx. Copper Weight (kg/km) | Approx Cable Weight (kg/km) |
---|---|---|---|---|
50300201014 | 2 x 0.14 | 4 | 9.38 | 14.2 |
50300301014 | 3 x 0.14 | 4.1 | 10.73 | 15.7 |
50300401014 | 4 x 0.14 | 4.4 | 12.52 | 17.9 |
50300501014 | 5 x 0.14 | 4.6 | 15 | 21 |
50300701014 | 7 x 0.14 | 5 | 18.24 | 24.9 |
50300801014 | 8 x 0.14 | 5.4 | 20.8 | 28.2 |
50301001014 | 10 x 0.14 | 6 | 25.05 | 33.6 |
50301201014 | 12 x 0.14 | 6.2 | 28.05 | 36.9 |
50301401014 | 14 x 0.14 | 6.4 | 31.45 | 40.8 |
50301501014 | 15 x 0.14 | 6.7 | 33.5 | 43.5 |
50301601014 | 16 x 0.14 | 6.7 | 34.66 | 44.7 |
50301801014 | 18 x 0.14 | 7 | 38.41 | 49 |
50302001014 | 20 x 0.14 | 7.5 | 42.18 | 54 |
50302101014 | 21 x 0.14 | 7.5 | 43.39 | 55.2 |
50302501014 | 25 x 0.14 | 8.2 | 51.24 | 64.5 |
50302801014 | 28 x 0.14 | 8.6 | 55.66 | 69.8 |
50303001014 | 30 x 0.14 | 8.6 | 58.27 | 72.4 |
50303201014 | 32 x 0.14 | 8.9 | 61.82 | 76.6 |
50303601014 | 36 x 0.14 | 9.2 | 67.85 | 83.5 |
50304001014 | 40 x 0.14 | 9.5 | 74.06 | 90.3 |
50304401014 | 44 x 0.14 | 10.2 | 81.35 | 99.2 |
50305001014 | 50 x 0.14 | 10.4 | 89.63 | 107.9 |
50300201025 | 2 x 0.25 | 4.9 | 14.92 | 22.4 |
50300301025 | 3 x 0.25 | 4.9 | 15.81 | 23.4 |
50300401025 | 4 x 0.25 | 5.3 | 19.47 | 27.9 |
50300501025 | 5 x 0.25 | 5.7 | 22.48 | 31.9 |
50300701025 | 7 x 0.25 | 6.2 | 28.32 | 38.8 |
50300801025 | 8 x 0.25 | 6.8 | 32.23 | 44.1 |
50301001025 | 10 x 0.25 | 7.6 | 39.1 | 52.9 |
50301201025 | 12 x 0.25 | 7.8 | 44.27 | 58.6 |
50301401025 | 14 x 0.25 | 8.1 | 50.02 | 65.2 |
50301501025 | 15 x 0.25 | 8.6 | 53.1 | 69.3 |
50301601025 | 16 x 0.25 | 8.6 | 55.36 | 71.6 |
50301801025 | 18 x 0.25 | 9 | 61.57 | 78.9 |
50302001025 | 20 x 0.25 | 9.6 | 67.53 | 86.6 |
50302101025 | 21 x 0.25 | 9.6 | 69.81 | 88.9 |
50302501025 | 25 x 0.25 | 10.5 | 82.36 | 104 |
50302801025 | 28 x 0.25 | 11.1 | 90.24 | 113.4 |
50303001025 | 30 x 0.25 | 11.1 | 94.82 | 118 |
50303201025 | 32 x 0.25 | 11.5 | 100.42 | 124.7 |
50303601025 | 36 x 0.25 | 12 | 109.27 | 134.9 |
50304001025 | 40 x 0.25 | 12.4 | 121.11 | 147.9 |
50305001025 | 50 x 0.25 | 13.6 | 147.73 | 177.9 |
50306101025 | 61 x 0.25 | 14.8 | 176.02 | 209.6 |
50300201034 | 2 x 0.34 | 5 | 15.27 | 22.9 |
50300301034 | 3 x 0.34 | 5 | 18.52 | 26.3 |
50300401034 | 4 x 0.34 | 5.4 | 22.72 | 31.4 |
50300501034 | 5 x 0.34 | 5.8 | 26.7 | 36.3 |
50300701034 | 7 x 0.34 | 6.3 | 34.45 | 45.2 |
50300801034 | 8 x 0.34 | 6.9 | 39.2 | 51.4 |
50301001034 | 10 x 0.34 | 7.8 | 47.64 | 61.8 |
50301201034 | 12 x 0.34 | 8 | 54.48 | 69.2 |
50301401034 | 14 x 0.34 | 8.4 | 61.93 | 77.5 |
50301501034 | 15 x 0.34 | 8.8 | 65.9 | 82.6 |
50301601034 | 16 x 0.34 | 8.8 | 68.97 | 85.6 |
50301801034 | 18 x 0.34 | 9.2 | 77.21 | 95 |
50302001034 | 20 x 0.34 | 9.8 | 84.65 | 104.2 |
50302101034 | 21 x 0.34 | 9.8 | 87.76 | 107.3 |
50302501034 | 25 x 0.34 | 10.8 | 102.99 | 125.3 |
50302801034 | 28 x 0.34 | 11.4 | 113.92 | 137.7 |
50303001034 | 30 x 0.34 | 11.4 | 120.13 | 143.9 |
50303201034 | 32 x 0.34 | 11.9 | 127.76 | 152.7 |
50303601034 | 36 x 0.34 | 12.4 | 139.2 | 165.5 |
50304001034 | 40 x 0.34 | 12.8 | 155.2 | 182.7 |
50305001034 | 50 x 0.34 | 14.1 | 189.54 | 220.7 |
50300201050 | 2 x 0.5 | 5.8 | 20.13 | 30.6 |
50300301050 | 3 x 0.5 | 5.8 | 25.08 | 35.8 |
50300401050 | 4 x 0.5 | 6.3 | 30.85 | 42.8 |
50300501050 | 5 x 0.5 | 6.8 | 36.84 | 50.1 |
50300601050 | 6 x 0.5 | 7.3 | 43.13 | 57.8 |
50300701050 | 7 x 0.5 | 7.4 | 47.71 | 62.6 |
50300801050 | 8 x 0.5 | 8.1 | 54.24 | 71.1 |
50301001050 | 10 x 0.5 | 9.1 | 66.98 | 86.6 |
50301201050 | 12 x 0.5 | 9.4 | 76.6 | 97.1 |
50301401050 | 14 x 0.5 | 9.9 | 87.26 | 109 |
50301601050 | 16 x 0.5 | 10.4 | 97.91 | 121.1 |
50301801050 | 18 x 0.5 | 10.9 | 109.29 | 134.1 |
50301901050 | 19 x 0.5 | 10.9 | 113.91 | 138.7 |
50302001050 | 20 x 0.5 | 11.8 | 120.19 | 148.8 |
50302401050 | 24 x 0.5 | 13 | 142.32 | 174.8 |
50302501050 | 25 x 0.5 | 13.1 | 146.98 | 179.5 |
50302701050 | 27 x 0.5 | 13.3 | 156.84 | 190.2 |
50303001050 | 30 x 0.5 | 13.8 | 172.11 | 206.9 |
50300201075 | 2 x 0.75 | 6.4 | 25.98 | 38.5 |
50300301075 | 3 x 0.75 | 6.5 | 32.85 | 45.6 |
50300401075 | 4 x 0.75 | 7 | 41.37 | 55.6 |
50300501075 | 5 x 0.75 | 7.5 | 49.35 | 65.1 |
50300701075 | 7 x 0.75 | 8.2 | 64.96 | 82.7 |
50300801075 | 8 x 0.75 | 9 | 74.16 | 94.2 |
50301001075 | 10 x 0.75 | 10.1 | 91.35 | 114.6 |
50301201075 | 12 x 0.75 | 10.4 | 106.17 | 130.4 |
50301801075 | 18 x 0.75 | 12 | 153.48 | 182.8 |
50302501075 | 25 x 0.75 | 14 | 207.72 | 243.5 |
50303001075 | 30 x 0.75 | 14.8 | 244.37 | 282.6 |
50300200001 | 2 x 1 | 7 | 31.67 | 46.6 |
50300300001 | 3 x 1 | 7 | 41.39 | 56.6 |
50300400001 | 4 x 1 | 7.6 | 51.91 | 68.9 |
50300500001 | 5 x 1 | 8.2 | 62.76 | 81.7 |
50300700001 | 7 x 1 | 9 | 83.12 | 104.4 |
50301000001 | 10 x 1 | 11.1 | 117.31 | 145.4 |
50301200001 | 12 x 1 | 11.5 | 136.9 | 166.2 |
50301800001 | 18 x 1 | 13.3 | 199.05 | 234.6 |
50302500001 | 25 x 1 | 15.6 | 270.56 | 314 |
50300201105 | 2 x 1.5 | 7.7 | 42.16 | 60.4 |
50300301105 | 3 x 1.5 | 7.8 | 55.88 | 74.5 |
50300401105 | 4 x 1.5 | 8.5 | 71.49 | 92.3 |
50300501105 | 5 x 1.5 | 9.2 | 86.5 | 109.6 |
50300601105 | 6 x 1.5 | 10 | 101.92 | 127.6 |
50300701105 | 7 x 1.5 | 10.1 | 115.53 | 141.6 |
50300801105 | 8 x 1.5 | 11.1 | 131.75 | 161.4 |
50301001105 | 10 x 1.5 | 12.5 | 163.84 | 198.4 |
50301201105 | 12 x 1.5 | 12.9 | 191.62 | 227.6 |
50301401105 | 14 x 1.5 | 13.5 | 220.6 | 258.9 |
50301601105 | 16 x 1.5 | 14.3 | 249.79 | 290.8 |
50301901105 | 19 x 1.5 | 15 | 294.69 | 338.5 |
50302401105 | 24 x 1.5 | 17.8 | 394.72 | 448.7 |
50302701105 | 27 x 1.5 | 18.2 | 437.24 | 492.7 |
50303701105 | 37 x 1.5 | 20.6 | 583.86 | 648.9 |
