| Part Number | No. of Cores & Nominal Cross Sectional Area(Sq. mm) | Approx. Cable Diameter (mm) | Approx. Copper Weight (kg/km) | Approx. Cable Weight (kg/km) |
|---|---|---|---|---|
| 040601010113 | 4 G 0.75 + 2 x (2 x 0.34) | 9.5 | 59.9 | 124 |
| 040601020113 | 4 G 1.5 + 2 x (2 x 0.75) | 12.1 | 103.0 | 195 |
| 040601030113 | 4 G 2.5 + (2 x 2 x 0.75) | 13.9 | 127.6 | 258 |
| 040601040113 | 4 G 4 + (2 x 0.75 + 2 x 1) | 15.8 | 182.8 | 351 |
| 040601050113 | 4 G 6 + (2 x 0.75 + 2 x 1) | 16.7 | 250.3 | 435 |
| 040601060113 | 4 G 16 + (2 x 2 x 1) | 23.5 | 626.3 | 1052 |
| 040601070113 | 4 G 1.5 +(2 x 0.75) | 11.7 | 76.9 | 174 |
| 040601080113 | 5 G 1.5 +(2 x 0.75) | 12.7 | 89.7 | 203 |
| 040601090113 | 7 G 1.5 +(2 x 0.75) | 12.4 | 115.1 | 203 |
| 040601100113 | 4 G 2.5 +(2 x 0.75) | 13.1 | 110.9 | 239 |
| 040601110113 | 7 G 2.5 +(2 x 0.75) | 15.2 | 174.6 | 335 |
