Part Number | Nominal Cross Sectional Area (Sq. mm) | No. of Wires | Strand Diameter (mm) | Width (mm) | Thickness (mm) |
---|---|---|---|---|---|
12090101000c | 35 | 36 X 48 | 0.16 | 25 | 3.0 |
12090102000c | 50 | 36 X 69 | 0.16 | 33 | 3.2 |
12090103000c | 70 | 48 X 72 | 0.16 | 35 | 4.5 |
12090104000c | 14 | 36 X 13 | 0.20 | 18 | 1.5 |
12090105000c | 16 | 36 X 15 | 0.20 | 20 | 1.6 |
12090106000c | 21 | 36 X 19 | 0.20 | 22 | 2.0 |
12090107000c | 25 | 36 X 22 | 0.20 | 22 | 2.5 |
12090108000c | 35 | 36 X 31 | 0.20 | 25 | 3.0 |
12090109000c | 50 | 48 X 33 | 0.20 | 33 | 3.2 |
12090110000c | 70 | 48 X 47 | 0.20 | 35 | 4.5 |
Part Number | Nominal Cross Sectional Area (Sq. mm) | No. of Wires | Strand Diameter (mm) | Width (mm) | Thickness (mm) |
---|---|---|---|---|---|
12070112000c | 55 | 48 X 64 | 0.15 | 33 | 2.5 |
12070113000c | 20 | 36 X 8 | 0.30 | 20 | 2.0 |
12070114000c | 30 | 36 X 12 | 0.30 | 25 | 2.4 |
12070115000c | 40 | 36 X 16 | 0.30 | 30 | 3.0 |
12070116000c | 50 | 36 X 20 | 0.30 | 30 | 3.5 |
