Part Number | No. of Cores & Nominal Cross Sectional Area(Sq. mm) | Approx. Cable Diameter (mm) | Approx. Copper Weight (kg/km) | Approx. Cable Weight (kg/km) |
---|---|---|---|---|
041200201050 | 2 x 0.5 | 5.3 | 8.7 | 39 |
041200311050 | 3G 0.5 | 5.7 | 13.0 | 48 |
041200411050 | 4G 0.5 | 6.3 | 17.4 | 60 |
041200511050 | 5G 0.5 | 6.8 | 21.7 | 71 |
041200711050 | 7G 0.5 | 8.0 | 30.4 | 99 |
041201211050 | 12G 0.5 | 9.5 | 52.1 | 147 |
041201811050 | 18G 0.5 | 11.4 | 78.1 | 214 |
041202511050 | 25G 0.5 | 13.7 | 108.5 | 306 |
041203011050 | 30G 0.5 | 14.3 | 130.2 | 344 |
041203411050 | 34G 0.5 | 15.6 | 147.5 | 403 |
041205011050 | 50G 0.5 | 18.5 | 216.9 | 574 |
041200201075 | 2 x 0.75 | 5.7 | 13.0 | 48 |
041200311075 | 3G 0.75 | 6.2 | 19.5 | 60 |
041200411075 | 4G 0.75 | 6.8 | 6.0 | 75 |
041200511075 | 5G 0.75 | 7.4 | 2.5 | 90 |
041200711075 | 7G 0.75 | 8.9 | 5.6 | 129 |
041201211075 | 12G 0.75 | 10.6 | 78.1 | 194 |
041201611075 | 16G 0.75 | 12.0 | 104.1 | 253 |
041201811075 | 18G 0.75 | 12.7 | 117.2 | 283 |
041202511075 | 25G 0.75 | 15.2 | 162.7 | 402 |
041200200001 | 2 x 1 | 6.1 | 17.4 | 57 |
041200310001 | 3G 1 | 6.6 | 26.0 | 72 |
041200410001 | 4G 1 | 7.3 | 34.7 | 90 |
041200510001 | 5G 1 | 8.0 | 43.4 | 110 |
041200710001 | 7G 1 | 9.6 | 60.7 | 157 |
041201210001 | 12G 1 | 11.4 | 104.1 | 237 |
041201410001 | 14G 1 | 12.3 | 121.5 | 276 |
041201610001 | 16G 1 | 13.0 | 138.8 | 311 |
041201810001 | 18G 1 | 13.9 | 156.2 | 353 |
041202510001 | 25G 1 | 16.4 | 216.9 | 491 |
041202610001 | 26G 1 | 16.4 | 225.6 | 498 |
041203410001 | 34G 1 | 18.9 | 295.1 | 658 |
041204110001 | 41G 1 | 20.6 | 355.8 | 786 |
041205010001 | 50G 1 | 22.3 | 433.9 | 936 |
041206510001 | 65G 1 | 25.4 | 564.1 | 1215 |
041200201105 | 2 x 1.5 | 6.8 | 26.0 | 75 |
041200311105 | 3G 1.5 | 7.4 | 39.1 | 96 |
041200411105 | 4G 1.5 | 8.1 | 52.1 | 119 |
041200511105 | 5G 1.5 | 9.1 | 65.1 | 150 |
041200711105 | 7G 1.5 | 9.9 | 91.1 | 189 |
041201211105 | 12G 1.5 | 12.9 | 156.2 | 322 |
041201811105 | 18G 1.5 | 15.0 | 234.3 | 456 |
041202511105 | 25G 1.5 | 17.6 | 325.4 | 630 |
041202611105 | 26G 1.5 | 17.8 | 338.4 | 649 |
041203411105 | 34G 1.5 | 20.2 | 442.6 | 841 |
041204111105 | 41G 1.5 | 22.0 | 533.7 | 1006 |
041204211105 | 42G 1.5 | 22.0 | 546.7 | 1017 |
041205011105 | 50G 1.5 | 24.0 | 650.8 | 1210 |
041200311205 | 3G 2.5 | 9.0 | 65.1 | 148 |
041200411205 | 4G 2.5 | 10.0 | 86.8 | 188 |
041200511205 | 5G 2.5 | 11.2 | 108.5 | 235 |
041200711205 | 7G 2.5 | 12.5 | 151.9 | 307 |
041201211205 | 12G 2.5 | 16.0 | 260.3 | 513 |
041201411205 | 14G 2.5 | 17.2 | 303.7 | 595 |
041200310004 | 3G 4 | 10.6 | 104.1 | 217 |
041200410004 | 4G 4 | 11.7 | 138.8 | 274 |
041200510004 | 5G 4 | 13.1 | 173.6 | 343 |
041200410006 | 4G 6 | 13.9 | 208.6 | 398 |
041200510006 | 5G 6 | 15.5 | 260.8 | 496 |
041200410010 | 4G 10 | 17.6 | 358.5 | 658 |
041200510010 | 5G 10 | 19.6 | 448.2 | 819 |
041200410016 | 4G 16 | 21.0 | 565.0 | 983 |
041200510016 | 5G 16 | 23.6 | 706.2 | 1236 |
