Part Number | No. of Cores & Nominal Cross Sectional Area(Sq. mm) | Approx. Cable Diameter (mm) | Approx. Copper Weight (kg/km) | Approx. Cable Weight (kg/km) |
---|---|---|---|---|
041300201050 | 2 x 0.5 | 7.2 | 24.5 | 76 |
041300311050 | 3G 0.5 | 7.5 | 30.2 | 86 |
041300411050 | 4G 0.5 | 8.1 | 36.3 | 102 |
041300511050 | 5G 0.5 | 8.6 | 42.4 | 116 |
041300711050 | 7G 0.5 | 9.1 | 54.3 | 136 |
041301211050 | 12G 0.5 | 11.5 | 84.2 | 216 |
041301811050 | 18G 0.5 | 13.5 | 117.5 | 301 |
041302511050 | 25G 0.5 | 15.12 | 156.9 | 386 |
041303011050 | 30G 0.5 | 16.02 | 185.1 | 442 |
041300201075 | 2 x 0.75 | 7.6 | 30.6 | 88 |
041300311075 | 3G 0.75 | 8.1 | 39.5 | 104 |
041300411075 | 4G 0.75 | 8.6 | 47.2 | 120 |
041300511075 | 5G 0.75 | 9.1 | 56.6 | 138 |
041300711075 | 7G 0.75 | 9.9 | 71.7 | 167 |
041301211075 | 12G 0.75 | 12.5 | 117.1 | 271 |
041301811075 | 18G 0.75 | 14.42 | 166.1 | 371 |
041302511075 | 25G 0.75 | 16.52 | 221.4 | 491 |
041303011075 | 30G 0.75 | 18 | 288.2 | 595 |
041300200001 | 2 x 1 | 8.1 | 37.3 | 102 |
041300310001 | 3G 1 | 8.4 | 47.3 | 116 |
041300410001 | 4G 1 | 8.9 | 58.8 | 136 |
041300510001 | 5G 1 | 9.7 | 69.4 | 161 |
041301210001 | 12G 1 | 13.22 | 145.7 | 316 |
041301810001 | 18G 1 | 15.42 | 210.4 | 442 |
041302510001 | 25G 1 | 17.4 | 286.0 | 580 |
041302610001 | 26G 1 | 17.4 | 295.7 | 588 |
041303410001 | 34G 1 | 20.2 | 392.5 | 788 |
041304110001 | 41G 1 | 22 | 466.3 | 927 |
041305010001 | 50G 1 | 23.7 | 554.0 | 1093 |
041300201105 | 2 x 1.5 | 8.9 | 48.2 | 126 |
041300311105 | 3G 1.5 | 9.3 | 64.0 | 148 |
041300411105 | 4G 1.5 | 10.0 | 82.3 | 180 |
041300511105 | 5G 1.5 | 10.5 | 96.8 | 202 |
041300711105 | 7G 1.5 | 11.5 | 128.8 | 254 |
041301211105 | 12G 1.5 | 15.2 | 216.8 | 439 |
041301611105 | 16G 1.5 | 16.7 | 295.2 | 555 |
041301811105 | 18G 1.5 | 17.7 | 317.5 | 617 |
041302511105 | 25G 1.5 | 20.7 | 426.7 | 840 |
041303411105 | 34G 1.5 | 23.5 | 563.9 | 1095 |
041300311205 | 3G 2.5 | 10.3 | 100.7 | 200 |
041300411205 | 4G 2.5 | 11.3 | 129.4 | 249 |
041300511205 | 5G 2.5 | 12.6 | 158.5 | 309 |
041300711205 | 7G 2.5 | 13.9 | 211.5 | 392 |
041300410004 | 4G 4 | 13.4 | 192.3 | 361 |
041300510004 | 5G 4 | 14.7 | 236.4 | 439 |
041300410006 | 4G 6 | 15.8 | 254.9 | 492 |
041300410010 | 4G 10 | 19.3 | 414.4 | 763 |
041300410016 | 4G 16 | 22.0 | 635.7 | 1076 |
