| Product Type | Specifications |
|---|---|
| PVC 70°C | IS 694, IS 8130 Class 1 & 2, IS 5831 Type A insulation & ST-1 sheath |
| HR 85°C | IS 694, IS 8130 Class 1 & 2, IS 5831 Type C insulation & ST-2 sheath |
| FR 70°C | IS 694, IS 8130 Class 1 & 2, IS 5831 Type A insulation & ST-1 ( FR ) sheath |
| HR 85°C + FR | IS 694, IS 8130 Class 1 & 2, IS 5831 Type C insulation & ST-2 (FR) sheath |
| FR-LSH | IS 694, IS 8130 Class 1 & 2, IS 5831 Type A insulation & ST-1 (FR-LSH) sheath |
| Part Number | No. of Cross | Nominal Cross Sectional Area (Sq. mm) | Nominal Insulation Thickness (mm) | Nominal Thickness of sheath | Maximum Overall Dimensions (mm) |
|---|---|---|---|---|---|
| 0112010102yz | 1 | 1 | 0.60 | 0.8 | 4.7 |
| 0112010202yz | 2 | 1 | 0.60 | 0.9 | 8.2 |
| 0112010302yz | 3 | 1 | 0.60 | 0.9 | 8.6 |
| 0112010402yz | 4 | 1 | 0.60 | 0.9 | 9.2 |
| 0112010502yz | 1 | 1.5 | 0.60 | 0.8 | 5 |
| 0112010602yz | 2 | 1.5 | 0.60 | 0.9 | 8.8 |
| 0112010702yz | 3 | 1.5 | 0.60 | 0.9 | 9.2 |
| 0112010802yz | 4 | 1.5 | 0.60 | 0.9 | 10.0 |
| 0112010902yz | 1 | 2.5 | 0.80 | 0.8 | 5.8 |
| 0112011002yz | 2 | 2.5 | 0.80 | 1.0 | 10.5 |
| 0112011102yz | 3 | 2.5 | 0.80 | 1.0 | 11.0 |
| 0112011202yz | 4 | 2.5 | 0.80 | 1.0 | 12.0 |
| 0112011302yz | 1 | 4 | 0.80 | 0.9 | 6.8 |
| 0112011402yz | 2 | 4 | 0.80 | 1.0 | 12.0 |
| 0112011502yz | 3 | 4 | 0.80 | 1.1 | 13.0 |
| 0112011602yz | 4 | 4 | 0.80 | 1.1 | 14.0 |
| 0112011702yz | 1 | 6 | 0.80 | 0.9 | 7.8 |
| 0112011802yz | 2 | 6 | 0.80 | 1.1 | 13.5 |
| 0112011902yz | 3 | 6 | 0.80 | 1.1 | 14.5 |
| 0112012002yz | 4 | 6 | 0.80 | 1.2 | 15.5 |
| 0112012102yz | 1 | 10 | 1.00 | 0.9 | 8.8 |
| 0112012202yz | 2 | 10 | 1.00 | 1.2 | 16.5 |
| 0112012302yz | 3 | 10 | 1.00 | 1.2 | 17.5 |
| 0112012402yz | 4 | 10 | 1.00 | 1.3 | 19.5 |
| 0112012502yz | 1 | 16 | 1.00 | 1.0 | 10.5 |
| 0112012602yz | 2 | 16 | 1.00 | 1.3 | 19.0 |
| 0112012702yz | 3 | 16 | 1.00 | 1.3 | 20.0 |
| 0112012802yz | 4 | 16 | 1.00 | 1.4 | 22.5 |
| 0112012902yz | 1 | 25 | 1.20 | 1.1 | 12.5 |
| 0112013002yz | 2 | 25 | 1.20 | 1.4 | 23.0 |
| 0112013102yz | 3 | 25 | 1.20 | 1.5 | 24.5 |
| 0112013202yz | 4 | 25 | 1.20 | 1.6 | 27.5 |
| 0112013302yz | 1 | 35 | 1.20 | 1.1 | 13.5 |
| 0112013402yz | 2 | 35 | 1.20 | 1.5 | 25.5 |
| 0112013502yz | 3 | 35 | 1.20 | 1.6 | 27.5 |
| 0112013602yz | 4 | 35 | 1.20 | 1.7 | 30.5 |
| 0112013702yz | 1 | 50 | 1.40 | 1.2 | 15.5 |
| 0112013802yz | 2 | 50 | 1.40 | 1.6 | 29.5 |
| 0112013902yz | 3 | 50 | 1.40 | 1.7 | 31.5 |
| 0112014002yz | 4 | 50 | 1.40 | 1.8 | 35.0 |
| 0112014102yz | 1 | 70 | 1.40 | 1.4 | 17.5 |
| 0112014202yz | 2 | 70 | 1.40 | 2.4 | 35.0 |
| 0112014302yz | 3 | 70 | 1.40 | 2.5 | 37.0 |
| 0112014402yz | 4 | 70 | 1.40 | 2.8 | 41.4 |
| 0112014502yz | 1 | 95 | 1.60 | 1.5 | 21.0 |
| 0112014602yz | 2 | 95 | 1.60 | 2.7 | 40.5 |
| 0112014702yz | 3 | 95 | 1.60 | 2.9 | 43.2 |
| 0112014802yz | 4 | 95 | 1.60 | 3.1 | 48.1 |
| 0112014902yz | 1 | 120 | 1.60 | 1.5 | 48.1 |
| 0112015002yz | 2 | 120 | 1.60 | 2.9 | 44.0 |
| 0112015102yz | 3 | 120 | 1.60 | 3.1 | 47.3 |
| 0112015202yz | 4 | 120 | 1.60 | 3.4 | 52.8 |
